Tiny implantable 'seeds' of tissue produce fully functional livers

In an effort to ease the shortage of livers, researchers at MIT, Rockefeller University and Boston University have developed a new way to engineer liver tissue by organising tiny subunits that contain three types of cells embedded into a biodegradable tissue scaffold.

In a study of mice with damaged livers, the researchers found that after being implanted in the abdomen, the tiny structures expanded 50-fold and were able to perform normal liver tissue functions. Their work has been published in the journal Science Translational Medicine.

“There are just not enough organs to go around. Our goal is that one day we could use this technology to increase the number of transplants that are done for patients, which right now is very limited,” said Professor Sangeeta Bhatia, a member of MIT’s Koch Institute for Integrative Cancer Research and Institute for Medical Engineering and Science.

These engineered livers could also help the millions of people who suffer from chronic liver disease but don’t qualify for a liver transplant, said Bhatia, the senior author of the study.

“These patients never really are transplant candidates, but they suffer from liver disease, and they live with it their whole lives. In that population you could imagine augmenting their liver function with a small engineered liver, which is an idea we’re pretty excited about,” she said.

Liver regeneration

The new implantable liver builds on previous work by Bhatia’s lab. In 2011, she developed an engineered tissue scaffold — about the size and shape of a contact lens — that could be implanted into the abdomen of a mouse. There, the liver cells would integrate with the mouse’s circulatory system, allowing it to receive a blood supply and begin performing normal liver functions.

However, those implants contained fewer than 1 million hepatocytes (the cells that perform most of the liver’s critical functions). A healthy human liver has about 100 billion hepatocytes, and Bhatia believes that at least 10–30% of that number would be necessary to help most patients.

To boost their hepatocyte population, the researchers decided to take advantage of a key trait of liver cells, which is that they can multiply to generate new liver tissue. “The liver is one of the only organs that can regenerate, and it’s the mature cells that divide, without an intermediate stem cell. That’s extraordinary,” Bhatia said.

Working with Christopher Chen, a professor of biomedical engineering at Boston University, Bhatia’s team designed microfabricated structures that incorporate spherical ‘organoids’ made of hepatocytes and fibroblasts, as well as cords of endothelial cells, which are the building blocks of blood vessels. These two types of structures are organised into patterns and embedded into fibrin, a tough protein normally involved in blood clotting.

Once the constructs are implanted into a mouse, they receive regenerative signals from the surrounding environment. These signals, which include growth factors, enzymes and molecules, are naturally produced when liver damage occurs. These signals stimulate the endothelial cells to form blood vessels and to release factors that stimulate hepatocyte proliferation, resulting in 50-fold expansion of the original tissue.

“The idea is that it’s the seed of an organ, and you organise it in a way that it can be responsive to these regenerative signals, but it’s a minimal unit of what you eventually want to end up with,” Bhatia said. “What’s really exciting about this is that the architecture of the tissue that emerges looks a lot like the liver architecture in the body.”

In this case, the researchers worked with Charles Rice, a virology professor at Rockefeller University, to implant the tissue into mice with a genetic liver disorder called tyrosinemia. When treated with a repair-inducing drug, the livers of these mice begin produce regenerative signals, and the researchers expect that patients receiving the transplants would produce similar signals. They are also looking into the possibility of embedding the implant with additional regeneration-promoting chemicals that they discovered in 2013.

Fully functional

The liver performs hundreds of functions for the body, most of which are related to regulation of metabolism, detoxification of harmful substances and bile production. Tests of the implanted human livers showed that examples of all of these functions were occurring normally in the host mice.

“This work is very innovative,” said Inder Verma, a professor of molecular biology at the Salk Institute, who was not involved in the research. “The use of primary hepatocytes, endothelial cells and stromal cells, leading to a 50-fold increase, is impressive and could pave the way for the growth of other organoids currently being employed by other labs.”

Intriguingly, the researchers also found that after implantation, the tissue began forming tiny precursors to bile ducts, which they had not designed. “The next step for us is to find out how they got there, whether we can make it happen faster and in a more organised way, and whether they’re functional,” Bhatia said.

The researchers are also exploring the best source of cells for these implants. Currently they are using liver cells from human organs that can’t be transplanted because they were on ice for too long after being removed from the donor or had some unusual anatomy. Other possibilities include using liver cells taken from the patient who will be receiving the tissue, which would avoid the need for immunosuppressive drugs, or using liver cells generated from induced pluripotent stem cells.

Image caption: Researchers have developed a new way to engineer liver tissue by organising tiny subunits that contain three types of cells embedded into a biodegradable tissue scaffold. This image shows vascularised engineered human liver tissue that has self-organised into a lobule-like microstructure. Image courtesy of Chelsea Fortin/Bhatia Lab/Koch Institute for Integrative Cancer Research under CC BY-NC-ND 3.0
